TISF Series Single Stage End Suction Centrifugal Pumps

The TIS, TISO, and TISF Series are designed for water supply, cooling water circulation, drainage, firefighting, and industrial service applications. Their optimized hydraulic design ensures efficient flow handling and stable operating performance across varying system requirements.

The pumps feature a robust end suction centrifugal construction suitable for continuous-duty industrial and commercial operation. Available in both 2 Pole and 4 Pole configurations, the series offers flexible performance options for high-flow and high-head applications.

Designed for dependable operation and easy maintenance, the TIS Series pumps are suitable for water distribution systems, irrigation networks, industrial circulation systems, and general utility services.

Features

  • Single stage end suction centrifugal pump design for efficient hydraulic performance
  • Available in 2 Pole and 4 Pole configurations
  • Reliable continuous-duty operation with low maintenance requirements
  • Suitable for water circulation, distribution, and industrial service applications
  • Robust construction for industrial and commercial operating environments

Applications

  • Cooling water and water distribution systems
  • Drainage and irrigation applications
  • General industrial service and liquid circulation systems
  • Firefighting and splitting system applications

Performance Range

Flow Range 2 Pole: 5 ~ 300 m³/hr; 4 Pole: 30 ~ 1280 m³/hr
Head Range 2 Pole: 10 ~ 160 m; 4 Pole: 5 ~ 65 meters
Frequency 50 Hz
Configurations TIS / TISO / TISF Series
Pole Configurations 2 Pole / 4 Pole
Operation Type Continuous Duty
Pump Type Single Stage End Suction Centrifugal Pump
Max Working Pressure 16 Bar
Max Inlet Pressure 6 Bar
Max Power 200 kW
Liquid Temperature -15°C ~ +110°C
Inlet Diameter DN 50 ~ DN 300
Outlet Diameter DN 32 ~ DN 250
