Noiseless Submersible Aerators
Over the past few decades, rapid industrial growth has significantly improved living standards, yet it has also created a critical challenge in the form of industrial effluent and household sewage. This vast quantity of wastewater has damaged ecosystems and severely polluted global water sources. At Toshio Technology, we are dedicated to reversing this trend by developing high-performance equipment specifically engineered for wastewater treatment.
In addition to our specialized wastewater and sewage pumps, we have developed the Noiseless Submersible Aerator, an essential component for efficient aeration in both Effluent Treatment Plants (ETP) and Sewage Treatment Plants (STP). Our unique submersible design provides a distinct advantage by combining efficient oxygen and air transfer with a powerful mixing effect. This dual-action process ensures the effective reduction of BOD and COD values, significantly improves Dissolved Oxygen (DO) levels, and maintains stable MLSS values for optimal treatment results.
AR Series Submersible Aerators
The AR Series Submersible Aerator uses a direct-coupled impeller to create a centrifugal vacuum, drawing atmospheric air into the housing to mix with water. This mixture is discharged at high velocity, creating powerful convection and breaking air into millions of tiny bubbles.
Because these bubbles are numerous and rise slowly, they provide a significantly higher oxygen transfer rate per BHP than traditional systems. This makes the AR Series a more efficient, compact alternative to conventional blower-diffuser setups. For optimal long-term maintenance, we recommend installing the unit on a concrete base with stainless steel guide tubes.
Air Flow Range
40~875 m3/hr
OTR (max)
Upto 85 (kg- O2/h)
Liquid Temp (max).
5° ~ 40°C
Frequency
50/60 Hz
MOC
Cast Iron
Features
- Submersible Direct Drive Motor which has low noise and high efficiency.
- It has a unique design for gas mixture chamber with large intake quantity. It can be mixed well with water. It has aeration and mixing function at the same time.
- Double mechanical seal, can extend useful life of the motor.
- Twelve radiated outlets, can bring a mass of bubbles.
- Netty inlet, can avoid impeller being blocked by foreign material.
- Use installation system to allow pump for easy installation, maintenance & repair.
Applications
- For BOD and COD Reduction in Waste Water Treatment
- For Aeration, Agitation and Mixing in Waste Water Treatment Plant
- Sewage Treatment Plant and industrial Waste Water Treatment facilities
